Place of Origin: | CHINA |
---|---|
Brand Name: | MAX |
Certification: | CE |
Model Number: | HM30W |
Minimum Order Quantity: | 1 |
Packaging Details: | 200KG |
Delivery Time: | 5-8 |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 9000 |
Product features and advantages:
1. The weld is smooth and beautiful, the welded workpiece is free of deformation and scar, and the welding is firm, reducing the subsequent grinding process and saving time and cost
2. Simple operation, simple training.
3. Independently develop the wobble welding joint, swing welding mode, adjustable spot width and strong welding fault tolerance, which makes up for the disadvantage of small laser welding spot, expands the tolerance range and weld width of processing parts, and obtains better weld forming
First generation hand-held welding joint, 3.0kg, without wobble welding technology.
The sixth generation wobble handheld welding joint, 0.65kg, lighter and smaller, more ergonomic
Other features:
1. The welding speed is fast, 2-10 times faster than the traditional welding. At least two welders can be saved for one machine a year
2. Laser welding requires no welding wire, less consumables, long service life, safer and more environmentally friendly.
Technical parameters:
Laser power: 1000W, 1500W
Laser wavelength: 1070 NM
Optical fiber length: standard 10M, max. 15M
Mode of operation: continuous/modulated
Welding speed range: 0-120 mm/s
Cooling water machine: industrial constant temperature water tank
Working environment humidity range: <70% no condensation
Welding thickness recommendation: 0.5-3mm
Welds requirement: not more than 0.5 mm
Working voltage: AV 220V
