Place of Origin: | China |
---|---|
Brand Name: | BCX |
Certification: | CE |
Model Number: | BCX-003 |
Minimum Order Quantity: | 1 |
Price: | 130USD |
Delivery Time: | 5-7 working days |
Payment Terms: | T/T, Western Union |
Supply Ability: | 10000set/year |
Laser Power: | 20W, 30W, 50W, 100W (optional) | Laser Wavelength: | 1064nm |
---|---|---|---|
Laser Type: | Fiber Laser | Laser Beam Quality: | M2:1.5 |
Repeat Frequency: | 20KHz-80KHz | Min Linear Width: | 0.01mm |
Laser source we use rex famous brand laser source, high stability, long life, no consumables.This is the key part of fiber laser marking machine.
Smart f theta lens with working area 110*110,200 * 200,300 x 300(mm)
The fiber laser beam through its focus to the work piece surface, so the energy is enough.This optical accessories control marking area.
High speed galvanometer scanning head adopts scanning laboratory technology, digital signal, high precision.
Famous brand directional EZCAD control system, easy to operate.
Power supply for galvo head and control card
To remove wheel to get the streng point to get focus.
Laser focus distance can be adjusted easily
Laser power
|
10w(20W,30W,50W optional)
|
Laser wavelength
|
1064nm
|
Laser type
|
Fiber Laser
|
Laser beam quality
|
M2:1.5
|
Repeat Frequency
|
20KHz-80KHz
|
Repeat Positioning Accuracy
|
0.005mm
|
Min linear width
|
0.01mm
|
Marking Depth
|
0.01-0.5mm
|
Standard Marking Area
|
110×110mm
|
Optional Marking Area
|
70×70mm/175×175mm
|
Rated Power Consumption
|
less 500W
|
Operating Voltage
|
220V/50Hz/15A
|
Graphic formate supported
|
PLT, BMP, JPG, PNG, TIP, PCX, TGA, ICO. DXF,etc
|
Working temperature
|
5-35 centigrade
|
Cooling
|
Air Cooling
|
