Place of Origin: | CHINA |
---|---|
Brand Name: | HM |
Certification: | CE |
Model Number: | HM |
Minimum Order Quantity: | 1 |
Price: | usd1000set |
Packaging Details: | 70*60*50 |
Delivery Time: | 8-10working days |
Payment Terms: | T/T, Western Union |
Supply Ability: | 10000set/year |
Graphic Format Supported: | AI,PLT,BMP,DWG,DXF | Cooling Mode: | Air Cooling |
---|---|---|---|
Condition: | New | Application: | Laser Marking |
Control Software: | EZCAD | Working Accuracy: | 0.001mm |
Keywords: | Fiber Laser Markng Machine,Laser Machine Price | Laser Power: | 20W /30w/ 50w(Optional) |
Laser Source Brand: | Raycus | Marking Area: | 110mmx110mm-175mmx175mm |
High Light: | 30W Mini Fiber Laser Marking Machine,Raycus Source Fiber Laser Marking Machine,1064nm Laser Engraving Machine |
Product description | |||||
CCD visual positioning laser marking machine | |||||
In industrial production, facing the problems of difficult feeding, poor positioning, and slow speed caused by the difficulty of fixture design and manufacturing in batch irregular marking, CCD camera marking is solved by using an external camera to capture feature points in real time. Automatic feeding, precise positioning and marking greatly improve the efficiency of marking.
|
Laser power | 10W 20W 30W 50W |
Supports graphical format | PLT, BMP, JPG, PNG, TIP, PCX, TGA, ICO, DXF |
Beam quality | m2 <2 |
Power stability | (8h) <± 1% rms |
Pulse repetition frequency | 20KHZ ---- 100KHZ |
Power consumed | <800W |
Minimum line width | 50μm |
Minimum character | 0.3mm |
Laser Wavelength | 1064nm |
Galvanometer Size | 110 * 110mm (optional) |
Whole machine power | 500w |
Cooling way | Air cooling |
Operating voltage | 110/220V ± 10% /,50/60HZ |
Ambient operating temperature | 15 ° C - 35 ° C |
Weight | 80KG |
Dimensions | 600H * 200W * 700L (mm) |
Packing | plywood wooden packaging |
